5 Lac / Piece
| Business Type | Manufacturer, Exporter, Supplier |
| Drive System | Servo-driven Carriage And Tool Movement For High Accuracy |
| Control System | PLC With Touchscreen HMI For Parameter Settings |
| Cutting Speed | High-speed Forward Movement For Faster Cutting Cycles |
| Click to view more | |
Product Details
Pipe Diameter Range
Suitable For Plastic Pipes From 16 Mm To 630 Mm
Cutting Type
Automatic Dust-free Precision Cutting System
Cutting Accuracy
Uniform Cutting Even With Slight Pipe Shape Irregularities
Cutting Flexibility
Supports Multiple Cutting Lengths In A Single Production Line
Tool Life Optimization
Optimized Cutting Speed Increases Cutting Tool Lifespan
Material Compatibility
Suitable For PVC, High-filled, And Special Plastic Materials
Machine Structure
Robust Heavy-duty Design For High-speed Continuous Operation
The ECM is an automatic cutting machine for plastic pipes from 16 to 630 mm. The advanced technology ensures uniform, dust-free cutting and is relatively insensitive to pipe shape irregularities. Tool movement and carriage are controlled by a servo drive for maximum precision.
Advantages :
- Multiple cutting lengths in one line
- Improved lifetime of cutting tools because of optimal cutting speed
- Faster movement towards the pipe which results in faster cutting
- Most parameter settings on touchscreen
- Excellent cut for any socketing device
- Robust design for high-speed lines and special PVC/high-filled materials
Specification
| Model | Unit | ETCM - 110 | ETCM - 200 | ETCM - 250 | ETCM - 315 | ETCM - 110/2 | ETCM- 200/2 |
| Pipe Range | MM | 20-110 | 20-200 | 50-250 | 90-315 | 20-110 | 20-200 |
| Cutting Speed(MAX) | mtrs./min | 20 | 12 | 10 | 6 | 20 | 12 |
| Clamping From | - | Top | Top | Top | Side/Top | Top | Top |
